Applications:
The machine is specially used to open the hard wastes:
1.All kind of fabric wastes:
Fabric clips from garments plant, used garments and cloths and waste fabric etc.
Output: 70 to 90kg/h.
Staple length of fiber: 16 to 21 mm.
2.All kinds of yarn wastes:
Yarn hard waste, selvedge waste, sizing yarn waste and waste thread etc.
Output: 80 to 100kg/h.
Staple length of fiber: 16 to 23mm.
Main Features:
1.Waste feeding:
Manual through conveyor lattice
2.Auto, continuous, cycling opening:
The wastes are fed by manual to the lattice. The un-opened wastes which are dropped into the bottom of machinery is carried by the bottom conveyor belts and suctioned by fans to No.1 to No.3 chute feeder separately. Auto, continuous, cycling opening is carried out till the wastes are opened into fibers.
3.Opening points arrangement:
Total seven opening points, No.1 to No.2 Hard wooden cylinder opener, 630cm diameter, with metallic saw wire and No.3 to No.7 licker-in opener, 250cm diameter, with metallic saw wire. The proper opening &cleaning points and duty to reduce damage of fiber.
4.Dust air exhaust (by pipes):
Exhaust dust air to dust filter.
5.Fiber collection:
