Thermal Mass Flow Meter
Brand | manas microsystems |
Application Media | Dry & Clean Air or Dry & Clean Compressed Gases |
Material | Stainless Steel |
Packaging Type | Corrugated |
Power Supply | 24 V DC |
Accuracy | +- 3 % of Actual Flow Rate between 100 % to 10 % of Flow Rate |
Model Number | Scirocco 1000 |
Service Fluid | Dry & clean compressed Air / Gas. (Mixture of gases not applicable). |
Line Size | DN20 |
End Connection | Flange |
Flow Velocity Range | 100 m/s max (at NTP Condition) |
Display | Blind/LCD 16/2 |
Output | 4-20 mA/RS 485, Pulse, Wireless Data Transfer. Wireless Data transfer (Optional). |
Operating Fluid Temperature | 0 - 100 Degree C |
Operating Fluid Pressure | 12 Bar Max |
Operating Ambient Temperature | 0 - 50 Degree C |
Temperature Drift at Ambient Temp | 0.008% / Degree C maximum of Full Scale in the range 0 to 60 DegreeC |
Ingress Protection | IP 65 for Transmitter (Sensor Excluded). |
Feature
Brand | manas microsystems |
Application Media | Dry & Clean Air or Dry & Clean Compressed Gases |
Material | Stainless Steel |
Packaging Type | Corrugated |
Power Supply | 24 V DC |
Accuracy | +- 3 % of Actual Flow Rate between 100 % to 10 % of Flow Rate |
Model Number | Scirocco 1000 |
Service Fluid | Dry & clean compressed Air / Gas. (Mixture of gases not applicable). |
Line Size | DN20 |
End Connection | Flange |
Flow Velocity Range | 100 m/s max (at NTP Condition) |
Display | Blind/LCD 16/2 |
Output | 4-20 mA/RS 485, Pulse, Wireless Data Transfer. Wireless Data transfer (Optional). |
Operating Fluid Temperature | 0 - 100 Degree C |
Operating Fluid Pressure | 12 Bar Max |
Operating Ambient Temperature | 0 - 50 Degree C |
Temperature Drift at Ambient Temp | 0.008% / Degree C maximum of Full Scale in the range 0 to 60 DegreeC |
Ingress Protection | IP 65 for Transmitter (Sensor Excluded). |
Description
The Thermal Dispersion Mass Flow Meter, Series Scirocco 1000 measuring principle is based on the fact that heat is drawn from a heated body when a fluid flows past.
A Thermal Dispersion Mass Flow Meter contains two Platinum RTD temperature sensors for this purpose. One sensor measures the current fluid temperature as a reference. The second sensor is heated and has a constant temperature differential relative to the first sensor. When the flow of air/gas starts heat is taken away from the warmer sensor. The amount of heat taken away is having a direct relation with the mass velocity of the fluid. This eliminates the need for temperature and pressure compensation.
Thermal Dispersion Mass Flow Meter, Series Scirocco 1000 is available with insertion probe type or Complete Spool type with proper end connection. Insertion probe can be installed directly on the pipe carrying compressed air, with the help of clamps supplied along with probe.
Features
- Direct measurement of mass flow.
- No pressure or temperature compensation required
- 20:1 turndown.
- Wireless data transfer possible. Remote readings available on wireless.
- Pulse, milliamps or RS485 output for networking
Other Details:
- End Connection: BSP(M) Threading/ Direct clamp mounting
- Line Size: DN20 to DN50 (For others consult factory).
