SMF Battery
| Model Number | AA63 |
| Initial Current: | 2.1 A |
| Power | 7 AH |
| Feature | Non Spillable |
| Is It Rechargeable | Rechargeable |
| Voltage | 12 V |
| No.Of Phase | Single Phase |
| Brand | Challenger |
| Minimum Order Quantity | 5 |
Feature
| Model Number | AA63 |
| Initial Current: | 2.1 A |
| Power | 7 AH |
| Feature | Non Spillable |
| Is It Rechargeable | Rechargeable |
| Voltage | 12 V |
| No.Of Phase | Single Phase |
| Brand | Challenger |
| Minimum Order Quantity | 5 |
Description
Product Details:-
- 12V7AH
- Selaed Lead Battery Last Recycled Or Disposed Of properly
- Cycle Use 14.4-15.0 V
- Your Partner In A Most Secure Future
- Standby Use 13.5-13.8 V
- Initial Current: less tha 2.1 A
Caution
- Do Not Short Terminals
- Do Not Charge In Sealed Enclosure
- Do Not Incenrate
Other Details:-
- Use in either standby [alarm panels and PSUs] or cyclic applications
- For cyclic application the correct charging circuit must be used
- Designed to operate for up to 5 years in normal service conditions
- 6 months shelf life
- Sealed lead acid
- Non spillable
- Spade terminals
- Nominal voltage: 12V
- Rated capacity (20hr rate): 7Ah
- Dimensions: Length: 151±1.5mm (5.94”)
- Width: 65±1mm (2.56”)
- Height: 94±1mm (3.70”
- Total Height: 100±1mm (3.94”)
- Weight (approx): 2.1kg (4.63lbs) ±3%
- Capacity (25??C) 20hr (10.5V) 7Ah 10hr (10.5V) 6.5Ah 1hr (9.60V) 4.5Ah
- Terminal Type T1/T2 Internal resistance (Fully charged, 25??C) Approx. 24m???
- Capacity affected by temperature (20AH) 40??C 102% 25??C 100% 0??C 85% -15??C 65%
- Self-discharge (25??C) 3 month Remaining capacity: 91% 6 month Remaining capacity: 82% 12 month Remaining Capacity: 65% Nominal
- operating temperature 25??C ±3??C (77??F ±5??F) Operating temperature range Discharge -15??C 50??C (5??F 122??F) Charge -10??C 50??C (14??F 122??F) Storage -25??C 50??C (-4??F 122??F)
- Float charging voltage (25??C) 13.60 to 13.80V Temp. compensation: -18mV/??C
- Cyclic charging voltage (25??C) 14.50 to 15.00V Temp. compensation: -30mV/??C
- Maximum charging current 2.1A
- Maximum discharge current 105A (5sec) Designed floating life (20??C) 5 years
- Use in either standby [alarm panels and PSUs] or cyclic applications
- For cyclic application the correct charging circuit must be used
- Designed to operate for up to 5 years in normal service conditions
- 6 months shelf life
- Sealed lead acid
- Non spillable
- Spade terminals
