Rare Earth Magnetic Drum Separator, Capacity: 15 Ton/Hour in Pune

700000 incl. GST

Description:

PERMAG’s Rare earth roll separator provides a unique inclined belt feeding system to maximize overall performance and efficiency.
The design of the magnetic rolls ensures the optimum combination of magnetic field strength and magnetic gradient to give the most effective separation.

FEATURES

Provides an alternative in handling a wide variety of materials which do not respond well to traditional methods of processing
Can recover particles with a wide range of magnetic susceptibility and particle size up to minus 325 mesh
3” and 4” diameter rolls and width ranging from 5” to 60” long
Cantilever design which allows for quick belt replacement by a single operator.
Standard models include single, double, and triple stage machines
High strength neodymium-boron-iron permanent magnets
Multiple separation stages available on one separator
Kevlar feed belt. Positive belt tracking features
Mounted vibratory feeder with control to provide consistent feed rate to the magnetic roll
Variable speed drive. Feed belt speeds up to 250 fpm using a variable frequency control
All stainless steel construction
Wide range splitter to segregate magnetics and non-magnetics
Flanged magnetic and non-magnetic product discharge chutes
Dust tight housing available
High temperature magnets available

Drum Diameter	300 mm
Drum Length	750 mm
Capacity	15 Ton/Hour
Type Of Magnet Used	Neodymium
Type Of Magnetic Separators	Double Drum Magnetic Separator
Dimensions (LxWxH) (mm)	Standard Roll Sizes - A) Dia 100 x 600mm(L) B) Dia 100 x 750mm(L) C) Dia 100 x 1,200mm(L)
Colour	Silver
Applications	Recycling Industry
Magnetization power	3.3 kw
Gauss Value	1800 Gauss
Belt Speed	60m/min
Country Of Origin	Made In India
Model No	Mag Clean 120
Brand	Permag Products
Minimum Order Quantity	1
