MAX TRAVELX: 4.55 in (115.5mm)Y: 5.05 in (128.3 mm)Z: 3.55 in (90.1mm)A: -25° to 135°B: Continuous Rotation(-9999° to 9999°)
Tested on G5 titanium,6061 aluminum, 303stainless, machinablewax, acetal
Accepts standardG Code.
| Brand | POCKET NC/Penta Machine |
| Model Name/Number | POCKET NC V2 -50 AND V2-1O |
| Z - Axis Travel | 3.55 in (90.1 mm) |
| Spindle Speed | 1,000-50,000 RPM* |
| Spindle Power Fanuc | 200 W (Max Power) |
| X - Axis Travel | 4.55 in (115.5 mm) |
| Y - Axis Travel | 3.55 in (90.1 mm) |
| Rapid Traverse X Axis | 60 in/min (1524 mm/min) |
| Rapid Traverse Y Axis | 60 in/min (1524 mm/min) |
| Rapid Traverse Z Axis | 60 in/min (1524 mm/min) |
| Number Of Tools | 1 |
| Tool Change System | Manual |
| Minimum Order Quantity | 1 |
MAX TRAVELX: 4.55 in (115.5mm)Y: 5.05 in (128.3 mm)Z: 3.55 in (90.1mm)A: -25° to 135°B: Continuous Rotation(-9999° to 9999°)
Tested on G5 titanium,6061 aluminum, 303stainless, machinablewax, acetal
Accepts standardG Code.
We have carved out a position in market by providing Detachable Type Auto loader. These detachable type autoloaders are accurately designed to excellence and are designed utilizing finest quality raw material and current technology. In addition, the detachable type auto loaders offered by us are accessible in an assortment of technical specifications and can be also efficiently modified as per client''s stipulation. Apart from this, the offered detachable type auto loaders are broadly demanded by the customers for their outstanding finish & can be availed at pocket friendly rates.
...
Product Information
Binding Groove
Thickness Measuring - Macanisam
adjusting nobe
auto
wight - 28kgs
...
Cone winding machine for yarn dyeing plant also used in remaining bottom winding as well as in other final package winding application, even package quality, precise length control optional, individual length control.
...
Automatic Spray machine for small equipment..
Can Use any type of paint - PU , Melamine , Water Base , UV ..
Perfect for Door Frame, Photo frame , Moulding , Skirting Baord ..,
300mm/ 400mm width with 4& 6 Iwata Gun with Plunger Pump ..
