Multiplexer unit-AI-DO-AO

Description:-

MAXIMUX-AI-16 and MAXIMUX-AI-32 are part of Lectrotek I/O modules for interfacing industrial/field inputs and outputs to PLC-based control systems.

These microprocessor based I/O interfacing products are innovative in terms application versatility, compactness and cost-effectiveness and offer value-for-money to clients looking
for low cost automation.
The MAXMUX-AO-… 16/32 accept respectively 16 or 32 analog 4-20mA inputs, and multiplex the same to transmit the data over RS-485 serial port to external PLCs, DCS, PC-based and other control systems.

The inputs have a load resistance of 100 ohms each. These can be addressed for readingtheir value, using Modbus-RTU standard protocol, for which register address are provided.The enclosure is ABS engg. plastic, for 35 mm DIN-rail mounting, in size 100 x 75 x 110 mm (WHD).
• 16 or 32 channels, 4-20 mA DC inputs.• Input load resistance 200 ohms.• Power supply 24VDC.• RS-485 serial port, Modbus-RTU protocol commands.• Wiring by screwed terminals, suitable for 1.5mm² wires• Interfaces with PLC systems over other protocols using  appropriate protocol converters.• Field interface module for PLC, DCS etc. control systems.• Advantages of using Maximux I/O modules:- Save cost of wiring involved with centralized I/O systems- Maximux I/O modules offer economy over PLC I/Os.- Low cost PC-based SCADA & industrial automation.

Specifications:-

Capacity : 16 or 32 channels, 4-20 mA DC inputs, load resistance 200 ohms.Output   :    RS-485 Modbus-RTU protocolRS-485 output modes : Slave mode of operation, responds on query by Master (PLC, PC etc.)Device serial number  : 001 to 255, programmable by user over serial port (password protected)Power on Display : LED providedPower supply  :24V DC +/- 5%, rating 1.5A max.Device serial number : 001 to 255.Wiring Screwed Terminals : Maximum 1.5 mm² wire sizeEnclosure : ABS, 100 x 75 x 110 mm mm (W x H x D),Protection : IP 40Mounting : 35 mm DIN rail mountedAmbient Temperature : 0 to 50 o CRelative Humidity :90% RH max. non-condensing.

Unpacking, Installation:Unpack the instrument and check for presence of this Operation Manual, physical damage if any. Report to the dealer for any shortages or warranty service/replacement.Typical wiring scheme for Maximux-AI-16/32 (example shown with PC, other schemes possible)
