Milk Flow Meter
| Application Media | Milk |
| Packaging Type | Corrugated Box |
| Power Supply | 85-265V AC |
| Machine Body Material | SS304 |
| Accuracy | +-0.5% |
| Brand | manas microsystems |
| Electronics Enclosure | Al. Die cast for Amplifier/Transmitter |
| Flow Range | Max 10 m/s |
| End conn. | SMS union / Tri clover clamp |
| Signal output | 4-20mA DC / pulse output |
| Repeatability | +-0.2% of reading |
| Ambient Temp. | 0 - 50 Degree C |
| Temperature Drift | 0.015% / Degreec maximum of Full Scale |
| Humidity | 90% R.H. maximum,non-condensing |
| Ingress Protection | IP 67 |
Feature
| Application Media | Milk |
| Packaging Type | Corrugated Box |
| Power Supply | 85-265V AC |
| Machine Body Material | SS304 |
| Accuracy | +-0.5% |
| Brand | manas microsystems |
| Electronics Enclosure | Al. Die cast for Amplifier/Transmitter |
| Flow Range | Max 10 m/s |
| End conn. | SMS union / Tri clover clamp |
| Signal output | 4-20mA DC / pulse output |
| Repeatability | +-0.2% of reading |
| Ambient Temp. | 0 - 50 Degree C |
| Temperature Drift | 0.015% / Degreec maximum of Full Scale |
| Humidity | 90% R.H. maximum,non-condensing |
| Ingress Protection | IP 67 |
Description
The Series SG-Sroat of Electromagnetic Flow Meters is Specifically designed for measurement of food liquids like milk, cream, juices of various fruits, pharma liquids etc. It is available with integral or remote version of transmitter. The transmitter can have built-in or remote totalizer display. Suitable end Connections of SMS Union or DIN Union or Tri-Clover Clamp is given as per Customer’s requirements. Special Models are available for mounting on Milk Tankers.
Features
- Full Stainless Steel Body
- End Connection in Union Coupling or Tri-clover Clamp
- Sizes available for 1” to 4” (DN25 -DN100)
- Highly Accurate and Extremely Linear
- Isolated 4-20 mA output Proportional to Flow Rate
- Option of Pulse Output available
