Metal Transparent CU Mesh, For Defence
| Material | Metal |
| Usage/Application | Defence |
| Usage | Defence, Industrial |
| Size | It can be Customised |
| Pattern | Plain |
| Features | Excellent EMI Shielding Effectiveness |
| Surface Finish | Smooth |
| Transparency Type | 80 % |
| Type (wire/inch) | 100 wire/inch (100 OPI) |
| Wire Diameter (mm) | 0.076mm |
| Sheets | As per requirement |
| Frequency | Up to 40 GHz |
| Minimum Order Quantity | 1 |
Feature
| Material | Metal |
| Usage/Application | Defence |
| Usage | Defence, Industrial |
| Size | It can be Customised |
| Pattern | Plain |
| Features | Excellent EMI Shielding Effectiveness |
| Surface Finish | Smooth |
| Transparency Type | 80 % |
| Type (wire/inch) | 100 wire/inch (100 OPI) |
| Wire Diameter (mm) | 0.076mm |
| Sheets | As per requirement |
| Frequency | Up to 40 GHz |
| Minimum Order Quantity | 1 |
Description
Specification / Parameters
Woven Meshes for shielding windows, apertures & displays where an Electronic enclosure requires shielding from Electro Magnetic Interference (EMI) or is emitting electromagnetic energy which may cause interference with another system but requires high level of visible light transmission or image clarity
Product Range:
· Blackened 100 opi Copper is a rugged mesh that is recommended for standalone use.
· Mesh is the proprietary mesh optimized for optical performance without sacrificing EMI Performance. This is only supplied in finished window formats Sigma & Ultra.
· Micromesh is an subtractive copper grid matrix with higher light transmission and optical clarity. This is only supplied in fully laminated windows
· Conventional plated and blackened stainless steel metal mesh are also available
|
Material |
Light % |
Surface Resistivity ???/Sq. Inch |
Format |
|
Mesh |
80 |
0.030 |
Fully laminated Sigma or Ultra Window |
|
MicroMesh |
89 |
0.050 |
Fully laminated glass window only |
|
50 opi 0.050 µm Blk Cu plated S/S |
75 |
0.025 |
Sheets 450 X 600 mm |
|
80 opi 0.050 µm Blk Cu plated S/S |
65 |
0.020 |
Sheets 450 X 600 mm |
|
100 opi 0.050 µm Blk Cu plated S/S |
53 |
0.020 |
Sheets 450 X 600 mm |
|
100 opi 0.050 µm OFL Blk Copper |
60 |
0.010 |
Sheets from 600 mm sq up to rolls 2000mm wide |
|
100 opi 0.050 µm unblk Copper |
60 |
0.010 |
Rolls 1200 mm wide |
|
EMI – ITO 15 Film |
82 |
15 |
Sheets from 350 mm sq upto rolls 762 mm wide |
