Features:
ØPVC Copper Wire Cross Section: 0.35 sq.mm to 1.5 sq.mm. Ø2 wires can be processed Max outer diameter 2.5 mm ØLength accuracy: Repeat accuracy
± (0.2 % of length> 500 & ±1 mm for length < 500mm)
ØWire length range: 1-10000mm ØShort Wire Length: Min 18 mm optional ØMax. stripping lengths: Full strip both sides 10 mm ØStraightening unit optional ØElectrical connection: 220 VAC ±5% 50/60 Hz ØCompressor required to utilized all functions of machine ØPneumatic connection for blade cleaning and tube bend action & if stripping on both sides is more than 6 mm ØMachine is Controlled with Microcontoller or PLC. ØMachine runs on imported Stepper Motors ØDimensions (W × H × D) 465 × 385 × 460 mm ØWeight: 60 kg ØSpeed 2000 (4000)wires /hr both side Cutting & stripping 100 mm length Single Wire( Double Wire)
Features:
ØPVC Copper Wire Cross Section: 0.35 sq.mm to 1.5 sq.mm. Ø2 wires can be processed Max outer diameter 2.5 mm ØLength accuracy: Repeat accuracy
± (0.2 % of length> 500 & ±1 mm for length < 500mm)
ØWire length range: 1-10000mm ØShort Wire Length: Min 18 mm optional ØMax. stripping lengths: Full strip both sides 10 mm ØStraightening unit optional ØElectrical connection: 220 VAC ±5% 50/60 Hz ØCompressor required to utilized all functions of machine ØPneumatic connection for blade cleaning and tube bend action & if stripping on both sides is more than 6 mm ØMachine is Controlled with Microcontoller or PLC. ØMachine runs on imported Stepper Motors ØDimensions (W × H × D) 465 × 385 × 460 mm ØWeight: 60 kg ØSpeed 2000 (4000)wires /hr both side Cutting & stripping 100 mm length Single Wire( Double Wire)
...
