Hydraulic Surface Grinder Machine
| Minimum Order Quantity | 1 Unit |
| Model Name/Number | FH50x100 |
| Overall Table Working Area (mm) | 500x1000 |
| Longitudinal table Travel (mm) | 1075 |
| Cross Feed Table Travel (mm) | 550 |
| Table Surface-Spindle Center distance (mm) | 550 |
| Vertical Feed Gradution | 0.002 mm |
| Spindle Speed | 1400 rpm |
| Max Height from Table to Grinding Wheel | 550 mm |
| Table Size | 500 x 1000 mm |
| Size of Grinding Wheel | 400x50x127 mm (DiaxWidthxBore) |
| Electric Motor Recommended | 3 Phase 5 HP |
| Cross Feed Gradution | 0.05 mm |
Feature
| Minimum Order Quantity | 1 Unit |
| Model Name/Number | FH50x100 |
| Overall Table Working Area (mm) | 500x1000 |
| Longitudinal table Travel (mm) | 1075 |
| Cross Feed Table Travel (mm) | 550 |
| Table Surface-Spindle Center distance (mm) | 550 |
| Vertical Feed Gradution | 0.002 mm |
| Spindle Speed | 1400 rpm |
| Max Height from Table to Grinding Wheel | 550 mm |
| Table Size | 500 x 1000 mm |
| Size of Grinding Wheel | 400x50x127 mm (DiaxWidthxBore) |
| Electric Motor Recommended | 3 Phase 5 HP |
| Cross Feed Gradution | 0.05 mm |
Description
Auto centralized lubrication system for ease of maintenance.Grinding spindle cartridge assembled with imported super precision bearings, grease-packed with high-quality grease for lifelong trouble-free
