| Automation Grade |
Automatic, Semi-Automatic, Manual |
| Power Consumption (kw) |
:1.5-2kwh electricity each hour |
| Minimum Order Quantity |
1 Piece |
Feature
| Automation Grade |
Automatic, Semi-Automatic, Manual |
| Power Consumption (kw) |
:1.5-2kwh electricity each hour |
| Minimum Order Quantity |
1 Piece |
Description
| Products information: |
| Control System : |
Microcomputer + Inside Air Operate & oil Hydraulic Pressure System |
| Voltage : |
110-220V 50-60Hz |
| Power : |
2.4 KW |
| Pressure : |
Automatic Oil Hydraulic Pressure (can be changed) |
| Pressure Range : |
0-16MPa |
| Working Pressure : |
12MPa+0.1MPa |
| Temperature Range : |
0-999 C |
| Working Temperature : |
110 C |
| Time Range : |
0-999 Seconds |
| Cycle Time : |
7-8 mintues |
| Opening Height : |
45mm |
| Cooling System : |
Automatic air cooling system |
| Lamination Size : |
A4 (220mm*310mm) |
| Work Efficiency : |
600pcs cards / hour |
| Lamination Opening : |
1 openings for heating & cooling |
| Lamination Layers : |
1-12 layers |
| Cooling System : |
Automatic water & air Cooling |
| Packing Weight : |
170kg |
| Power Consumption : |
1.5-2kwh electricity each hour |
| Operate Person : |
1 |
|
Shivraj Enterprises
