ETAP Based Intelligent SLD Preparation & Electrical Manual Creation

We are offering electrical system modeling in a SOFTWARE TOOL “ETAP”, which builds an electrically live SLD of your system and does all required background calculations to generate results. These reports can be used directly for cost effective decision making without compromising any technical requirement. You can also explore this as an effective documentation tool for your electrical system as against creating AUTOCAD pictures.

ETAP is a very effective tool for short circuit analysis of electrical system with any complexity. Such analysis is used for validating “Short circuit ratings” of various system components. The analysis reports can be directly used for  Relay Coordination through ETAP. The output gives various relay settings to achieve required coordination to ensure intended safety and gradation. This Documentation will help you to achieve the compliance as per IS 732, IS 60909, IEEE 1584, NFPA 70-E & OSHA-29.
