Elgi 20 HP Electric Powered Trolley Mounted Compre

Keeping in the mind various requirements of our clients, we are offering premium quality Electric Powered Trolley Mounted Compressor that converts power into kinetic energy by compressing and pressurizing air. The offered compressor is manufactured using quality tested components and ultra-modern technology at vendors’ end. Apart from this, provided compressor is available in varied specifications and designs as per the requirements of our clients. The provided compressor is offered at nominal prices.

Features:


• Centralized contractor based control panel
• Centralized control panel for ease of use
• Perfect finish
  Other Details:

  • Automatic star delta starter provided
  • Products available from 22-75kW
  • Quiet and emission free operation
  • Galvanized steel and powder coated canopy for corrosion resistance
  • Centralized contractor based control panel with 220V starting contractor
  • Tow bars designed for safe highway running
  • Centralized control panel for ease of use
  • Energy efficient eta V profile air ends
  • TEFC squirrel cage motors with class F insulation
  • Easy maneuverability allows quick turns and climbing slopes
  • Large access doors for ease of maintenance
    Applications:

    • Quarry
    • Industrial air (Standby)
    • Construction & breaker, chipping hammers, cleaning, concrete boom pumps, diaphragm pumps
      Specifications:

      Model	Power kW	FAD m3/min	FAD CFM	Max Pressure. Bar	Max Pressure. PSI
      E 22T-7	22	3.7	131	7	100
      E 37T-7	37	6.7	238	7	100
      E 45T-7	45	8.3	294	7	100
      E 75T-7	75	14.6	514	FAD m3/min	100
      E 75T-9.5	75	12.5	440	9.5	135
      E 75T-10.5	75	11.8	416	10.5	150 Additional Information Item Code 126-to-294-cfm
