Laser Type |
CO2 Glass Tube |
Laser Power |
130 Watt (150 /180 Watt Laser Tube Optional) |
Format Supported |
AI, BMP, PLT. DXF, DST etc |
Standard Dust Collector |
4 Sets of Bottom Exhaust Fans 9 EC |
Power Supply |
AC 220V + 5%,50/60 Hz |
Moving System |
Stepper motor system |
Processing Area |
1250 mm x 2500 mm / 1300 mm x 1800 mm |
Positioning Accuracy |
+/- 0.1 mm |
Feature
Laser Type |
CO2 Glass Tube |
Laser Power |
130 Watt (150 /180 Watt Laser Tube Optional) |
Format Supported |
AI, BMP, PLT. DXF, DST etc |
Standard Dust Collector |
4 Sets of Bottom Exhaust Fans 9 EC |
Power Supply |
AC 220V + 5%,50/60 Hz |
Moving System |
Stepper motor system |
Processing Area |
1250 mm x 2500 mm / 1300 mm x 1800 mm |
Positioning Accuracy |
+/- 0.1 mm |
Description
- SIL series Large Format Non-metal Laser Cutting System
- Gantry Type Structure, High precision imported belt drive system
- Hiwin Linear Guide rail with stable and high precision transmission.
- Stepper Motor and drive system Technology. (Servo motor Optional)
- DSP based controller for offline work with 32mb file space.
- Light & Solid Beam Structure with superior dynamic performance, module design
- Fixed Optical path system ensures consistency of cutting.
- 130watt DC CO2 Laser Glass Tube with 10 Months Guarantee (150 /180watt Laser Tube Optional)
- Fixed Steel Strips (Optional Honey Comb Available on Demand)
- Red Beam pointer
|
