Button Magnets
“CRYSTAL” Button Magnets which are made in four sizes specially designed in “Alnico” to give a highly efficient magnet suitable for magnetic indicators and drives.
Designed for applications where height is too restricted for conventional deep Pot magnets.
Ideal for magnetic fasteners in machine tools, workshops & in office displays.
They can be fixed by non-magnetic screw to any non-ferrous materials. Supplied complete with plated keeper.
Special sizes can also be manufactured.
Square and rectangular shape also available.
Specifications:
Sr. No. | Cat. No. | Diameter (OD) |
Height (H) |
Threading | Depth of Threading (D) |
Magnetic Pull kg |
1 | AA-1925 | 12 mm | 10 mm | M 5 | 3-4mm | 0.6 |
2 | AA-1926 | 20 mm | 12 mm | NIL | NIL | 1.6 |
