Brand

GSCLOK

Equivalent To

STAUFF, SWAGELOK, PARKER

Color

PP - GREEN,
AL - SILVER,
PA - BLACK

Locking Screw

STANDARD SERIES - M6 X 25 MM TO M6 X 100 MM
HEAVY SERIES – M10 X 45 MM TO M30 X 300 MM

Clamp Body Material

POLYPROPYLENE, ALUMINUM, POLYAMIDE

Size Range

STANDARD SERIES  - 1 /4'' TO 2 ½'' &  6 MM TO 76.1 MM
HEAVY SERIES – 1/4" TO 8" &  6 MM TO 219 MM

Type

STANDARD (LIGHT DUTY),  HEAVY DUTY & TWIN CLAMP,
MULTI LAYER

Pressure

UPTO 6000 PSI

Material

JAWS – POLYPROPYLENE, ALUMINUM, POLYAMIDE
TOP & BOTTOM PLATE AND BOLT – MS & STAINLESS STEEL 304, 316

Stainless Steel Surface Treatment

STEEL – ZINC COATED (A3C), TRIVALENT
STAINLESS STEEL –NATURAL , ELECTROPLATED

Standard

DIN 3015 : PART 1, PART 2 & PART 3
