30 mm Automatic Traub Machine For Industrial
| Round Bar Capacity | 30 mm |
| Usage/Application | Industrial |
| Distance Collet to Tailstock Face | 360 mm |
| Maximum Turning Length | 90 mm |
| Voltage | 240V |
| Phase | Three Phase |
| Material | MS |
| Automatic Grade | Automatic |
| Power Source | Electric |
| Feed drive monitor | 0.5 HP |
| Spindle speeds(12 steps) | 4000 RPM |
| Products Rate | 2100 Pcs/Hr |
| Work spindle motor | 2.2 HP |
Feature
| Round Bar Capacity | 30 mm |
| Usage/Application | Industrial |
| Distance Collet to Tailstock Face | 360 mm |
| Maximum Turning Length | 90 mm |
| Voltage | 240V |
| Phase | Three Phase |
| Material | MS |
| Automatic Grade | Automatic |
| Power Source | Electric |
| Feed drive monitor | 0.5 HP |
| Spindle speeds(12 steps) | 4000 RPM |
| Products Rate | 2100 Pcs/Hr |
| Work spindle motor | 2.2 HP |
Description
We have attained a notable position in the market by offering the finest quality array of Traub Type Automat Machine.
Special Feature
Cabinet:
- M.S. Strong 10mm steel fabricated structure duly reinforced avoid vibration and its precisely machined to maintain accuracy. Arrow-32 base is specially designing to accommodate more chip area with coolant motor provision for Arrow 32.
Spindle:
- Main spindle is made of case hardened steel from forgings and hardened and ground to maintain 5 micron accuracy. All threads are thread grounded. Imported bearing used in spindle assembly. Arrow 32 spindle designed with four bearing to withstand heavy load.
Guide Shafts:
- These shafts are duly hardened & ground and hard chrome done for increased life.
Vertical Slide & Cross Slide:
- All moving slides are made of Spheroid graphite iron, and machined & scrapped to avoid frequent wear & tear.
Bar Feed Systems:
- Gravity weight operated system for arrow 25. Silent bar feed system with guide support bearings for arrow 32
Electrical:
- All electrical are reputed make and free from maintenance
